U.A.14
SEL-421 Relay Users Guide Date Code 20090715
Firmware and Manual Versions
Instruction Manual
Reference Manual
Section 1
Added Frequency Estimation Provided by Synchrophasor.
Section 4
Added the Ethernet card as one of the available communications interfaces for the Phasor Measurement
Protocol.
Section 7
Added Table 7.2 for the Time and Date Management setting IRIGC.
Added Table 7.4 Ethernet Port Settings for Synchrophasors.
Changed FREQ to FREQ_PM (frequency measurement using phasor measurement quantities) in Table 7.9.
Added synchrophasor protocol availability when EPMIP := Y.
Revised example logic settings in Table 7.15.
Section 10
Added Table 10.16 for the Time and Date Management setting IRIGC.
20061215 Note: This version was not released from the factory. The 20070223 version contains the following changes.
Users Guide
Section 1
Added Alias Settings and Auxiliary
{TRIP}/{CLOSE}
Pushbuttons to Features.
Added INT3 to Models and Options.
Added INT3 to SEL-421 Versions and Supported Features.
Added INT3 and Auxiliary {TRIP}/{CLOSE} Pushbuttons to Specifications.
Section 2
Added INT3 to Control Inputs.
Added Figure 2.12.
Added INT3 to Tab le 2.3 and Table 2.4.
Added INT3 to I/O Interface Board Jumpers.
Added Figure 2.22.
Added Auxiliary {TRIP}/{CLOSE} Pushbutton and Breaker Status LED Jumpers (select models only) with
Table 2.8, Table 2.9, and Table 2.10.
Updated Figure 2.26 to include optional pushbuttons.
Added Figure 2.32.
Add INT3 to Control Inputs.
Added Auxiliary {TRIP}/{CLOSE} Pushbuttons and OPEN/CLOSED LEDs (select models only) to
Connection.
Added Figure 2.51.
Section 4
Added Alias Settings to Tab le 4.5.
Edited Figure 4.13 and Figure 4.14 for Display Points Text Size parameter.
Added Alias Settings.
Added Figure 4.15, Figure 4.16, and Figure 4.17.
Section 5
Added Figure 5.2.
Updated Front-Panel Layout for HMI changes: expanded pushbuttons, expanded target LEDs, tri-color
LEDs, and auxiliary {TRIP}/{CLOSE} pushbuttons.
Updated Figure 5.5, Figure 5.11, and Example 5.2 to include double-height Display Points.
Updated Display Points and Table 5.4 and Tab le 5.5 to include Text Size parameter.
Updated Relay Elements (Relay Word Bits) for Alias impact.
Updated Operation and Target LEDs for HMI changes: expanded target LEDs and tri-color LEDs.
Updated Figure 5.43 for expanded target LEDs.
Added Table 5.11.
Updated Recloser Status for expanded target LEDs.
Added Miscellaneous Status and Synchrophasor Status for expanded target LEDs.
Updated Figure 5.44, Table 5.13, and Figure 5.45 for expanded pushbuttons.
Table A.5 Instruction Manual Revision History (Sheet 4 of 16)
Revision Date Summary of Revisions
