U.2.26
SEL-421 Relay User’s Guide Date Code 20090715
Installation
Jumpers
Figure 2.24 Major Component Locations on the SEL-421 INT5 (or INT8) I/O
Board
Fast Hybrid Control Outputs
JMP2A
JMP2B
JMP1A
JMP1B
J8
Fast Hybrid Control OutputsControl Inputs
Rear of Relay
Courtesy of NationalSwitchgear.com
