Operation - Work application
6 - 67
830 / 07.2012
Original operating instructions
Extending the
running gear
1 Unlock and remove the 4 locking bolts (1) on the telescoping
running gear of the undercarriage.
2 Fasten a sufficiently rated suspension gear (2) on the track
wheel carrier.
3 Pull the track wheel carrier out to the stop with a suitable
towing machine.
4 Reinsert the 4 locking bolts (1) and secure.
