Operation - Work application
6 - 68
830 / 07.2012
Original operating instructions
Retracting
the running gear
DANGER
Danger of accident through tipping of the machine!
The machine is not operational with retracted running gear.
1 Unlock the 4 locking bolts (1) on the extension gear for the
telescope of the undercarriage and remove.
2 Push the track wheel carriers together.
3 Reinsert the 4 locking bolts (1) and secure.
