Operation - Work application
6 - 71
830 / 07.2012
Original operating instructions
Retracting
the running gear
DANGER
Danger of accident through tipping of the machine!
The machine is not operational with retracted running gear.
1 Unlock the 4 locking bolts (1) on the extension gear for the
telescope of the undercarriage and remove.
2 Enable telescoping with switch (2).
3 Use switch (3) to retract the undercarriage.
4 Reinsert the 4 locking bolts (1) and secure.
