microScan3 Pro I/O
Devices with a max. protec‐
t
ive field range of 9.0 m
≤ 9.0 m, details: see "Sensing range", page 189
Scanning range of the collision protection field
1)
Scan cycle time 40 ms ≤ 15 m
Scan cycle time 50 ms ≤ 19 m
Scanning range of the refer‐
enc
e contour field
Same as protective field range, see "Sensing range", page 189
Scanning range of the con‐
tour detection field
Same as protective field range, see "Sensing range", page 189
Warning field range
Devices with a max. protec‐
t
ive field range of 4.0 m
≤ 40 m
Devices with a max. protec‐
tive field range of 5.5 m
≤ 40 m
Devices with a max. protec‐
tive field range of 9.0 m
≤ 64 m
Distance measurement range
Devices with a max. protec‐
t
ive field range of 4.0 m
≤ 40 m
Devices with a max. protec‐
tive field range of 5.5 m
≤ 40 m
Devices with a max. protec‐
t
ive field range of 9.0 m
≤ 64 m
Fields ≤ 128
Simultaneously monitored fields
Devices with a max. protec‐
t
ive field range of 4.0 m
≤ 8
Devices with a max. protec‐
tive field range of 5.5 m
≤ 8
Devices with a max. protec‐
t
ive field range of 9.0 m
≤ 4
Simultaneous cut-off paths
Devices with a max. protec‐
tive field range of 4.0 m
≤ 8
Devices with a max. protec‐
t
ive field range of 5.5 m
≤ 8
Devices with a max. protec‐
tive field range of 9.0 m
≤ 4
Field sets ≤ 128
Monitoring cases ≤ 128
Scanning angle 275° (–47.5° … 227.5°)
Protective field resolution 30 mm, 40 mm, 50 mm, 60 mm, 70 mm, 150 mm, 200 mm
2)
Angular resolution
Devices with a max. protective field range of 4.0 m
Scan cycle time 30 ms 0.51°
Scan cycle time 40 ms 0.39°
Devices with a max. protective field range of 5.5 m
Scan cycle time 30 ms 0.51°
TECHNICAL DATA 13
8025424/1ELL/2022-01-21 | SICK O P E R A T I N G I N S T R U C T I O N S | microScan3 Pro I/O
179
Subject to change without notice
