SICK microScan3 Pro I/O User Manual

Name Use Data type Definition Values Safety implica‐
t
ion
TriggerDeviceRebootWithout‐
Network
Additional func‐
tion
BOOL Restarting safety func‐
tion and connections
Restarts the device
without ending the net‐
work stack. The internal
switch function is not
interrupted.
0 = no restart Parameter with
implication for
the safety func‐
tion
0-1-0 = device
r
estart
(duration of sta‐
tus 1 ≥ 120 ms)
1 = ignored
TriggerResetCutOffPath01 Safety function BOOL Reset Cut-off path 01
R
eset of cut-off path 01
after activation of the
restart interlock
0 = no reset Safety-relevant
parameter
0-1-0 = reset
(duration of sta‐
tus 1 ≥ 60 ms)
TriggerResetCutOffPath02
…
T
riggerResetCutOffPath08
Safety function BOOL Reset Cut-off path 02
… 08
Reset of cut-off path 02
… 08 after activation of
the restart interlock
2)
0 = no reset Safety-relevant
parameter
0-1-0 = reset
(duration of sta‐
tus 1 ≥ 60 ms)
TriggerRunMode Safety function BOOL Start safety function
R
estarts the safety
function, e.g. if it
was stopped or after
an application error.
(The device must be
restarted after a device
error.)
0 = no start com‐
mand
Safety-relevant
parameter
0-1-0 = start
safety function
(duration of sta‐
tus 1 ≥ 120 ms)
1 = ignored
1)
Control inputs 9 (E1) to 16 (H2) are only available with microScan3 Pro.
2)
Cut-off paths 5 to 8 are only available for the Pro performance package.
13.7.1.1.2 Output of the device (input of the control)
Table 43: Output of the device (input of the control)
Name Use Data type Definition Values Safety implica‐
tion
ApplicationError Diagnostics BOOL Application error
Signals whether an
application error is
present, causing the
safety function to be
paused. To resolve this,
rectify the cause of the
error and then restart
the safety function.
0 = no applica‐
tion error
Parameter with‐
out safety impli‐
cation
1 = application
er
ror
ContaminationError Diagnostics BOOL Contamination error
Opt
ics cover is dirty. All
safety outputs in the
OFF state. Clean the
optics cover.
0 = no contami‐
nation error
Parameter with
implication for
the safety func‐
tion
1 = contamina‐
tion error
ContaminationWarning Diagnostics BOOL Contamination warning
Opt
ics cover is dirty.
Clean the optics cover.
0 = no contami‐
nation warning
Parameter with‐
out safety impli‐
cation
1 = contamina‐
t
ion warning
13 TECHNICAL DATA
196
O P E R A T I N G I N S T R U C T I O N S | microScan3 Pro I/O 8025424/1ELL/2022-01-21 | SICK
Subject to change without notice

SICK microScan3 Pro I/O Specifications

General

Scanning angle	275°
Number of fields	128
Dimensions	102 mm x 152 mm x 106 mm
Number of safety outputs	2
Number of OSSD outputs	2
Scanning range	5.5 m
Protective field range	5.5 m
Resolution	30 mm
Number of monitoring cases	128
Response time	60 ms
Interfaces	Ethernet, USB
Operating temperature	+50 °C
Protection class	IP65
Supply voltage	24 V DC
Storage temperature	+70°C
Operating voltage	24 V DC (16.8 V DC ... 28.8 V DC)
Housing material	Plastic
Connection type	Male connector
