Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
9 Reserved
10 Reserved
11 Reserved
12
1)
TriggerReset‐
CutOf
f‐
Path08
TriggerReset‐
CutOff‐
Path07
TriggerReset‐
CutOff‐
Path06
TriggerReset‐
CutOff‐
Path05
TriggerReset‐
CutOff‐
Path04
TriggerReset‐
CutOff‐
Path03
TriggerReset‐
CutOff‐
Path02
TriggerReset‐
CutOff‐
Path01
13 Reserved
14 Reserved
15 Reserved TriggerDevi‐
ceReboot‐
WithNetwork
TriggerDevi‐
ceRebootWi‐
thoutNet‐
work
1)
Cut-off paths 5 to 8 are only available for the Pro performance package.
13.7.1.2.2 Assembly 104: Input of the device, output of the controller
CIP S
afety
Update cycle: 5 ms (or a multiple of this, depending on RPI)
Length: 8 bytes
Switching between monitoring cases via dual-channel information, like with devi‐
ces with locally-connected static control inputs.
Monitoring case switching via dual-channel speed information, similar to devices
with locally connected incremental encoders
Table 45: Assembly 104
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Speed2Valid Reserved Speed1Valid Reserved ActivateCa‐
seS
witching
Reserved
1 control input
8 (D2)
control input
7 (D1)
control input
6 (C2)
control input
5 (C1)
control input
4 (B2)
control input
3 (B1)
control input
2 (A2)
control input
1 (A1)
2
1)
control input
16 (H2)
control input
15 (H1)
control input
14 (G2)
control input
13 (G1)
control input
12 (F2)
control input
11 (F1)
control input
10 (E2)
control input
9 (E1)
3 Reserved
4 Speed1
5
6 Speed2
7
1)
Control inputs 9 (E1) to 16 (H2) are only available with microScan3 Pro.
13.7.1.2.3 Assembly 105: input of the device, output of the control
CIP S
afety
Update cycle: 5 ms (or a multiple of this, depending on RPI)
Length: 8 bytes
Switching between monitoring cases via dual-channel information, like with devi‐
ces with locally-connected static control inputs.
Monitoring case switching via safe speed information
Table 46: Assembly 105
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
0 Reserved SafeSpeed‐
V
alid
ActivateS‐
tandbyMode
StopAlarm‐
Detection
ActivateCa‐
seSwitching
TriggerRun‐
Mode
13 TECHNICAL DATA
200
O P E R A T I N G I N S T R U C T I O N S | microScan3 Pro I/O 8025424/1ELL/2022-01-21 | SICK
Subject to change without notice
