Siemens SIMOCODE pro System Manual

Logic modules
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
11-29
Settings
Formulae
Fig. 11-21: Calculator formulae
Calculator Description
Calculator 1 - Input Any value (2 bytes/1 word)
Range: 0 - 65535
Calculator 1 - Output Calculated value (2 bytes/1 word)
Range: 0 - 65535
Calculator 1 - Counter Range: -32766 to +32767, increment 1
Calculation 1 - Denominator Range: 0 - 255, increment 1
Calculator 1 - Offset Range: -32766 to +32767, increment 1
Calculator 2 - Input 1 Any value (2 bytes/1 word)
Range: 0 - 65535
Calculator 2 - Input 2 Any value (2 bytes/1 word)
Range: 0 - 65535
Calculator 2 - Output Any value (2 bytes/1 word)
Range: 0 - 65535
Calculator 2 - Counter 1 Range: -128 to +127, increment 1
Calculator 2 - Denominator 1 Range: 0 - 255, increment 1
Calculator 2 - Counter 2
1)
Range: 0 - 255, increment 1
Calculator 2 - Denominator 2
1)
Range: -128 to +127, increment 1
Calculator 2 - Offset Range: -2147483648 to +2147483647, increment 2
Calculator 2 - Operating mode 1 or 2
Calculator 2 - Operator
1)
+, -, *, /
1) Only relevant for operating mode = 1
Table 11-15: Calculator settings
Input 1
Input 2
Calculator 1
Counter
Denominator
Offset
Output
Input
*
Input
+
Calculator 2
Counter 1
Denominator 1
Operator
Output
Input 1
*
Input 1
Counter 2
Denominator 2
Offset
*
Input 2
+
Operating mode 1
Calculator 2
Counter 1
Denominator 1
Output
*
Input 1, input 2
Offset
+
Operating mode 2
Input 2
(High)
(Low)
