12.0 Trip monitoring 0/4-20 mA> Bit[2] 0, 1, 2, 3 0 0 = ON
(always)
1 = ON+
(always, not
TPF)
2 = RUN
(motor ON, not
TPF)
3 = RUN+
(motor ON, not
TPF,
start-up
override)
AM
12.2
Warning monitoring 0/4-20 mA> Bit[2] 0, 1, 2, 3 0 AM
12.4 Trip monitoring 0/4-20 mA< Bit[2] 0, 1, 2, 3 0 AM
12.6 Warning monitoring 0/4-20 mA< Bit[2] 0, 1, 2, 3 0 AM
13.0 Monitoring limit 1 Bit[2] 0, 1, 2, 3 0 BU2
13.2 Monitoring limit 2 Bit[2] 0, 1, 2, 3 0 BU2
13.4 Monitoring limit 3 Bit[2] 0, 1, 2, 3 0 BU2
13.6 Monitoring limit 4 Bit[2] 0, 1, 2, 3 0 BU2
14.0 Reserved Bit[2] 0
14.2 Reserved Bit[2] 0
14.4 Reserved Bit[2] 0
14.6 AM - Active inputs Bit[2] 0, 1, 2 0 0 = 1 input
1 = 2 inputs
2 = 3 inputs
AM
15.0 DM - Delay inputs Bit[2] 0, 1, 2, 3 10 ms 1 Offset 6ms DM1 DM2
15.2 AM - Response for open circuit Bit[2] 1, 2, 3 2 0 =
Deactivated
1 = Signaling
2 = Warning
3 = Tripping
AM
15.4 EM - Response to an external earth
fault
Bit[2] 1, 3 1 EM
15.6 EM - Response to warning of an
external earth fault
Bit[2] 0, 1, 2 0 EM
16.0 Reserved Bit[2] 0
16.2 Reserved Bit[2] 0
16.4 DM-F - Test requirement response Bit[2] 0, 1, 2 0 0 =
Deactivated
1 = Signaling
2 = Warning
3 = Tripping
DM-F
16.6 DM-F - Safety-oriented tripping
response
Bit[2] 0, 1, 2, 3 0 DM-F
17.0 TM - Trip response T> Bit[2] 1, 3 3 TM
17.2 TM - Warning response T> Bit[2] 0, 1, 2 2 TM
17.4 TM - Response to a sensor fault/
out of range
Bit[2] 0, 1, 2, 3 2 TM
17.6 TM - Active sensors Bit[2] 0, 1, 2 2 0 = 1 sensor
1 = 2 sensors
2= 3 sensors
TM
Byte.
Bit
Designation
(PRM group)
Type Range Unit De-
fault
Note Informa-
tion
Table B-14: Data record 132 - Extended device parameters 1 (Cont.)
