Siemens SIMOCODE pro System Manual

Data formats and data records
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
B-33
18.0 Trip response P> Bit[2] 0, 1, 3 0 0 =
Deactivated
1 = Signaling
2 = Warning
3 = Tripping
UM
18.2 Warning response P> Bit[2] 0, 1, 2 0 UM
18.4 Trip response P< Bit[2] 0, 1, 3 0 UM
18.6 Warning response P< Bit[2] 0, 1, 2 0 UM
19.0 Trip response cos phi< Bit[2] 0, 1, 3 0 UM
19.2 Warning response cos phi< Bit[2] 0, 1, 2 0 UM
19.4 Trip response U< Bit[2] 0, 1, 3 0 UM
19.6 Warning response U< Bit[2] 0, 1, 2 0 UM
20.0 Trip response 0/4-20 mA> Bit[2] 0, 1, 3 0 AM
20.2 Warning response 0/4-20 mA> Bit[2] 0, 1, 2 0 AM
20.4 Trip response 0/4-20 mA< Bit[2] 0, 1, 3 0 AM
20.6 Warning response 0/4-20 mA< Bit[2] 0, 1, 2 0 AM
21.0 Reserved Bit[2] 0
21.2 Reserved Bit[2] 0
21.4 Reserved Bit[2] 0
21.6 Reserved Bit[2] 0
22.0 Response - External fault 5 Bit[2] 1, 2, 3 1 0 =
Deactivated
1 = Signaling
2 = Warning
3 = Tripping
BU2
22.2 Response - External fault 6 Bit[2] 1, 2, 3 1 BU2
22.4 Reserved Bit[2] 0
22.6 Reserved Bit[2] 0
23.0 Analog value recording - Trigger
edge
Bit[2] 0, 1 0 0 = Positive
1 = Negative
BU2
23.2 Reserved Bit[2] 0
23.4 Reserved Bit[2] 0
23.6 Reserved Bit[2] 0
24.0 Reserved Bit[2] 0
24.2 Reserved Bit[2] 0
24.4 Reserved Bit[2] 0
24.6 Reserved Bit[2] 0
25.0 Timer 3 - Type Bit[2] 0, 1, 2, 3 0 0 = With
closing
delay
1 = Closing
delay with
memory
2 = With
opening
delay
3 = With
fleeting
closing
BU2
25.2 Timer 4 - Type Bit[2] 0, 1, 2, 3 0 BU2
Byte.
Bit
Designation
(PRM group)
Type Range Unit De-
fault
Note Informa-
tion
Table B-14: Data record 132 - Extended device parameters 1 (Cont.)

Siemens SIMOCODE pro Specifications

General

Protection Class	IP20
Mounting Type	DIN rail mounting
Rated Operational Voltage	24 V DC
Rated Current	Up to 820 A
Protection Functions	Overload, short-circuit, phase failure, asymmetry, ground fault, motor stall
Operating Temperature Range	-25°C to +60°C
Communication Protocols	PROFIBUS DP, PROFINET, Modbus RTU
Analog Outputs	Up to 2
Temperature Monitoring	PTC/KTY, RTD (PT100/PT1000)
Digital Outputs	Relay outputs, Solid-state outputs
Analog Inputs	0/4-20mA, PT100/PT1000
