Siemens SINAMICS S120 Combi User Manual

Topology rules for DRIVE-CLiQ
SINAMICS S120 Combi
Manual, 11/2017, 6SL3097-4AV00-0BP7
123
Table 5- 5 Assigning the DRIVE-CLiQ interfaces at the DMx20 to assign a direct measuring system to the feed axes.
DRIVE-CLiQ interface
Feed axis
X500 X501 of the TM54F
X102 of the PPU
1)
X100 … X103 of the NCU
X501 Feedrate 1 at the S120 Combi
X502
Feedrate 2 at the S120 Combi
X503
Feedrate 3 at the S120 Combi (4 axes Power Modules)
X504
Feedrate 1st expansion axis at the Motor Module
X505
Feedrate 2nd expansion axis at the Motor Module
1)
Only then, if a TM54F is not used
