Expanding the Operator Interface (BE1) 08/2005
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
BE1/5-134 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
5.5 List of selectable states in HMI Advanced
Setting tasks in HMI Advanced
In general, the following conditions apply to all tasks:
No configuration: Maintains current state
Configuration with 0: Reverts to the initial state of an operating area.
5.5.1 Machine operating area
In the Machine operating area, the status is always dependent on the status of the
machine (AUTO, MDA, JOG, REF). The following can be accessed via the PLC
key:
1.) The main screen for the relevant mode
State Mode
group
Machine funct. Displays
0 JOG REF JOG/REF main screen
0 JOG none JOG main screen
0 JOG REPOS REPOS main screen
0 MDA none MDA main screen
0 MDA TEACH MDA/Teach main screen
0 MDA REF MDA/REF main screen
0 AUTO none Auto main screen
2.) The main actual value screens for each mode (softkey vertical 6)
State Mode
group
Machine funct. Displays
10 JOG none Zoom actual values JOG
20 MDA none Zoom actual values MDA
30 AUTO none Zoom actual values Auto
3.)
Possibly still in jog / MDA
State Mode
group
Machine funct. Displays
60 JOG none Handwheel selection JOG
70 JOG none Increment selection JOG
80 MDA none Handwheel selection MDA
Switching between the WCS and MCS is possible via the PLC.
5.5.2 Parameters operating area
It is not possible to move from the current screen in this area.
