Commissioning HMI Advanced (IM4) 08/2005
3 Creating user alarm texts
© Siemens AG, 2005. All rights reserved
IM4/3-154 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
3.2 Structure of User Alarms
Alarm numbers
The following alarm numbers are available for the cycle alarms, compile cycle
alarms, and PLC alarms:
Number range Description Effect Deletion
60000 - 60999 Cycle alarms
(Siemens)
Display, NC start disable Reset
61000 - 61999 Display, NC start disable,
stop motion after
executing the pre-decoded
blocks
Reset
62000 - 62999 Display Cancel
63000 - 64999 Reserved
65000 - 65999 Cycle alarms (user) Display, NC start disable Reset
66000 - 66999 Display, NC start disable,
stop motion after
executing the pre-decoded
blocks
Reset
67000 - 67999 Display Cancel
68000 - 69000 Reserved
70000 - 79999 Compile cycle alarms
400000 - 499999 PLC alarms general
500000 - 599999 PLC alarms for channel
600000 - 699999 PLC alarms for axis and
spindle
700000 - 799999 PLC alarms for user
800000 - 899999 PLC alarms for sequence
cascades/graphs
Format of text file for cycle alarm texts
The number range indicated in the list is not available with every number (see
Reference: /FB/ P3 ”Basic PLC Program”, Lists)
The structure of the text file for cycle alarms and compile cycle alarms is as follows:
Alarm number Display Help ID Text or alarm number
60100 1 0 "No D number %1 is programmed"
60101 1 0 60100
... ... ... ...
65202 0 1 "Axis %2 in channel %1 is still moving"
// Alarm text file for cycles in English
