1.2.4 Expanding a general category
Adding a new category
A group of instructions via which instructions can be displayed is stored behind a
general category heading.
A line for the category definition contains the following 3 parameters:
Category definition
Technology code "r"/Category ID/Category name
In this case, the text file could contain the following line:
r/2/Travel commands
r is a predefined setting for category declarations.
2 is the category ID used to assign instructions to the
category.
Travel commands category name.
The "/" character separates the parameters and may only be used as a text
character in the last parameter.
The length of the category name is limited by the display and may not, for example,
exceed 40 characters with a standard type size of 8pt.
The following category IDs are reserved:
Table 1-2 Category IDs
Category ID User
0...49 Siemens
50...99 Machine manufacturer
100 and over End user
The following category IDs are provided in the Siemens text file as standard:
Table 1-3 Pre-assigned category IDs
Categ.
ID
Category name
Categ.
ID
Category name
1 Preparatory Functions 13 Program Handling
2 Travel Commands 14 Standard Cycles
3 Path Action 15 Measuring Cycles
4 Feedrate 16 Measurement
5 Spindle 17 Synchronized Actions
6 Axis Handling 18 Interrupt Handling
7 M Functions 19 String/Field operators
8 H Functions 20 Math. Functions/Operators
9 Offsets 21 Definitions
10 Transformations 22 High-Language Elements
11 Tool Management/
Compensations
23 Parameters
12 Technology Functions 24 System Variables
