Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-78 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
[conn HMI_3]
conn_1= NCU_1
conn_2= NCU_2
conn_3= NCU_3
conn_4= NCU_4
EXTCALL_conns=conn_1, conn_2, conn_3, conn_4
; conn_i Identifier for the NCUs from which the HMI
can be accessed (see note)
; Description of significant net parameters
[param network]
bus= opi
; HMI descriptions
[param HMI_3]
HMI_typ = 0x40
HMI_......
; NCU components definition
[param NCU_1]
type =NCU_573
nck_address= 11
plc_address= 11
name = NCU1
...
; Reference to the file with symbols for PLC signals from NCU_1
PlcSymbolFile=PlcSym
Note
The entry EXTCALL_Conns … is only needed in the main operating field in the
NETNAMES.INI file, not in the secondary operating fields.
Details can be found in
Reference: /FB/ B3 "Multiple Operator Panel Fronts and NCUs"
2.4.16 Transferring Display MD from HMI Embedded Systems
Application
he transfer of proven display machine data from HMI Embedded to HMI Advanced
with PCU 50 / PCU 70 is of interest, particularly when using ShopMill/ShopTurn.
This can be done with the standard scope of functions of HMI Embedded and HMI
Advanced.
Initial situation
In HMI Embedded, display machine data are controlled in the NCU; in HMI
Advanced, they are controlled on the hard disk of the PCU 50/PCU 70.
