Siemens SINUMERIK 840D Commissioning Manual

08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-75
4.18 Available display machine data
Please refer to the following documentation, available on DOCONCD, for
descriptions of all machine-data displays:
References: /AMD/ Detailed machine data description
Legend
Target systems:
Adv HMI Advanced
Emb HMI-Embedded
HT6 Handheld terminal 6
OP30 Operator panel OP 030
MT ManualTurn
SM ShopMill
ST ShopTurn
Filter:
H01 ShopMill
H02 ShopTurn
H03 ManualTurn
H04 Access levels
H05 Standard machine
MD number Identifier
Filter
Cross
reference:
Unit Name Data type Read/write
protection
PLC Default value Min. value Max. value Activation SW version
9000 LCD_CONTRAST
H05
CR: A2
- Contrast BYTE 3/4
OP30, Adv, Emb OP30: 7, Adv: 7,
Emb: 7
0 15
Power On -
9001 DISPLAY_TYPE
H05
CR: A2
- Type of operator panel
9002 external monitor
BYTE 0/0
OP30, Adv, Emb OP30: 1, Adv: 1,
Emb: 1
0 2
Power On
9002 DISPLAY_MODE CR: A2
-
(1: black and white, 2: color)
BYTE 3/4
OP30, OP30: 0,
0 2
Power On 1
9003 FIRST_LANGUAGE
H05
CR: A2
- Foreground language BYTE 3/4
OP30, Emb OP30: 1, Emb: 1
1 2
Power On 1.1
9004 DISPLAY_RESOLUTION
H05
CR: A2
- Display resolution BYTE 3/4
OP30, Adv, Emb OP30: 3, Adv: 3,
Emb: 3
0 5
Power On -
9005 PRG_DEFAULT_DIR
H05
CR: A2
- Basic setting Program directory BYTE 3/4
OP30, Emb OP30: 1, Emb: 1
1 5
IMMEDIATE
LY
-
