Commissioning HMI Advanced (IM4) 08/2005
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
IM4/2-142 SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
2.7.6 Example 4: Positioning Input/Output Field
By specifying position parameters in the COM file, you can insert the comment
field, or input and output field, at any position within the display area.
Part program
N15 MMC("CYCLES,PICTURE_ON, T_SK.COM; Screen2,
GUD4.DEF,,,C1","S")
N20 TEST_3 = 5
N30 MMC("CYCLES,PICTURE_OFF","N")
N40 M30
Dialog screen file (*.COM)
//C2(Screen12)
(R///Var.Name/R/TEST_3/6000,2800,8000/ 200,3000,7500)
Position of comment field:
First value = 0 --> automatic positioning to default value
No specification --> Standard positioning as for PCU 20
Position of input/output field
The two parameters each consist of three numerical values; these specify the
position and length of the field. The values are specified in Twips, with 15 Twips
roughly corresponding to one pixel.
The field height is defined as being 250 Twips.
Meaning of values:
(./6000,2800,8000/....)
Distance from lefthand screen
edge
Distance from above screen
edge
Len
th of field
It is possible to graphically configure 16 comment and 16 input or output fields.
Where there are more than 16 fields, they can be controlled via a scroll bar.
