08/2005 Starting Up HMI Embedded (IM2)
9 Configure Windows in the NC Program
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/9-127
9.3 Example program 1: MMC command without
acknowledgment
Parts program
N10
MMC("CYCLES,PICTURE_ON,T_SK.COM,SCREEN1,GUD4.DEF,,,A1","N")
N20 TEST_1 = 1
N25 G4 F10
N30 MMC ("CYCLES, PICTURE_OFF", "N")
N40 M30
Dialog screen file (*.COM)
//C1(SCREEN1)
(R///USER VAR TEST_1/W/TEST_1///)
Text variable
TEXT VARIABLES]
A1 =............Example1: MMC command without acknowledgment………
Sequence
The user variable TEST_1 from GUD4.DEF with header A1 is displayed for a short
time.
The hold time comes from parts program block N25.
Example 1: MMC command without acknowledgement
ANW.VAR TEST_1
1.000000
