Siemens SINUMERIK 840D Commissioning Manual

08/2005 Expanding the Operator Interface (BE1)
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/5-141
5.8.6 Tools zero offsets
State Function Remark
600 Tool list
610 Tool wear
620 OEM tool list
630 Magazine
640 Zero offset
650 R parameters
660 *)
670 Spindles
User data:
680 User data
5.8.7 Run screen
State Function Remark
910 Run Screen in manual
mode
920 Run Screen in MDA
mode
930 Run Screen in Automatic
mode
Note
Screens marked *) may also have been configured using the Expand user
interface system. In this case, the screen configured by the user is addressed.
In ShopMill and ShopTurn, the active states in DB82 DBW44 are sent to the PLC.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
