Siemens SINUMERIK 840D Commissioning Manual

Expanding the Operator Interface (BE1) 08/2005
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
BE1/5-138 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
5.7.5 Program
State Function
400 Machining plan / G code editor
Simulation:
412 Top view
413 3-level view
414 Volume model
5.7.6 Messages/alarms
State Function Remark
500 Messages
510 Custom screen form
520 Custom screen form
5.7.7 Tools zero offsets
State Function Remark
600 Tool list
610 Tool wear
620 OEM tool list
630 Magazine
640 Zero offset
650 R parameters
660 Custom screen form
680 User data
5.7.8 Run screen
State Function Remark
910 Machine Manual run screen
920 MDA run screen
930 Machine Auto run screen

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
