Page #234 background imageLoading...
Page #234 background image
Online Help (HE1) 08/2005
1 Programming Help
© Siemens AG, 2005. All rights reserved
HE1/1-22 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Note
In cases where the index is large, the call file can be generated automatically
using Microsoft Excel:
• Insert text file (*.txt) in Excel
• Insert a column
• Enter the name of the PDF file in the first line.
• Execute "Edit - Fill".
• Now delete the column "search terms", so that the following syntax remains:
<pdf file name> <ID> <page>
840d_pg.pdf 44 155
• Copy data and
• save the file as "txt".
1.4 ISO Mode Help
1.4.1 Function
The following 840D-specific Help function is displayed per default:
• Help in the Editor
• Alarm Help
• Machine Data Help
If "ISO dialect 0" Help functions are to be displayed, the data to be displayed must
be distinguished, since the same commands can have different meanings, for
example.
To do this, the "IF.INI" file has been expanded in the [TEXTFILES] section to
include the entry SiemensI=Cst.dir\ifit_.com (turning technology) or
SiemensI=Cst.dir\ifim_.com (milling technology), under which the path (Cst.dir)
and name (ifit_.com or ifim_.com) are specified for the ISO Mode Short Help
"ASCII".
The relevant Long Help "pdf" can then be called from the Short Help "ASCII".
IF.INI[TEXTFILES]
[TEXTFILES]
;text files containing the information shown in the Help
system
Siemens=Cst.dir\Ifs_.com
SiemensI=Cst.dir\ifit_.com or ifim_.com
Manufacturer=
Enduser=
