Expanding the Operator Interface (BE1) 08/2005
7 Configuring and Working Environment
© Siemens AG, 2005. All rights reserved
BE1/7-174 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
71. Filename.bxx
Partial binary files, which have to be processed for reasons of compatibility with
Real mode and when starting Protected mode. These files are only searched for in
the currently selected directory.
CF card directory structure with HMI Embedded
The user data of the configuration for Expand user interface is stored on the CF
card in the /card/user/sinumerik/cycles/proj directory.
• The associated texts (aluc.txt, or aluctx.s0x) are stored in the corresponding
language directories:
/card/user/sinumerik/cycles/lngs/xxx,
where xxx represents the language (deu, eng, rus, etc.)
• The associated bitmaps are stored in the resolution-specific directories:
/card/user/sinumerik/cycles/ico/ico640, .../ico800, .../ico1024
All other files (*.com, *.ini) for Expand user interface are stored under:
/card/user/sinumerik/cycles/proj
/card/oem/sinumerik/cycles/proj
/card/addon/sinumerik/cycles/proj
/card/siemens/sinumerik/cycles/proj
7.4.2 Search method for COMMON.COM
In the case of HMI Embedded, a search is made for file COMMON.COM on the NC
only. The following directories are searched:
• NC / user cycles directory
• NC / manufacturer cycles directory
• NC / standard cycles directory
Configuration file COMMON.COM is handled separately. In order to activate the
changes in this file, HMI Embedded WIN32 must be restarted.
No PC system
A connection to the NC is established.
CUS directory in the data management directory specified in dh.ini
CMA directory in the data management directory specified in dh.ini
CST directory in the data management directory specified in dh.ini
COM directory in the data management directory specified in dh.ini
Wizard directory on RAM disk
