Expanding the Operator Interface (BE1) 08/2005
5 Configuring OP Hotkeys and PLC Keys
© Siemens AG, 2005. All rights reserved
BE1/5-136 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
5.6 List of selectable states in HMI Embedded
State entries in HMI Embedded
There are only two configuration options for the state in HMI Embedded:
No configuration: Maintains current state.
Configuration with 0: The basic state of an operating area is activated.
5.7 List of selectable states in ShopMill
These designated functions can be configured with the Expand user interface
system. If this type of configuration is available, it is activated. Otherwise, the
standard ShopMill screen will appear.
5.7.1 Machine Manual
State Function Remark
19
Manual main screen
2
T,S,M, ...
21
Set basic ZO
30
Workpiece zero
5 Set up edge
7
Custom screen form
31 Orienting the edge Custom screen form
32 Distance 2 edges Custom screen form
33 Right-angled corner Custom screen form
8 Any corner Custom screen form
34 Rectangular pocket
9 1 hole Custom screen form
35 2 holes
36 3 holes
37 4 holes
38 Rectangular spigot
10 Circular spigot Custom screen form
39 Circular spigot
40 Circular spigot
41 Circular spigot
42 Set up level
11 Calibration probe length Custom screen form
12 Calibration probe radius
50
Measuring tool
16 Length manual Custom screen form
17 Diameter manual Custom screen form
13 Length auto Custom screen form
14 Diameter auto Custom screen form
51
Custom screen form
15 Calibration probe Custom screen form
52 Calibration fixed point Custom screen form
