08/2005 Commissioning HMI Advanced (IM4)
2 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
IM4/2-79
Case 1:
Case 2:
Anzeige-MD
Anzeige-MD
HMI-Embedded
NCU1
HMI-Advanced
Anzeige-MD
NCU1
Netz-LW
Floppy Disk
Anzeige-MD
HMI-Advanced
NCU2
PCU 50
PCU 50
PCU 20
HMI-Embedded
Operating sequence
The transfer involves two steps:
1. Copy the display machine data from the HMI Embedded System to an
external data medium.
2. Insert the display machine data in the PCU 50/PCU 70 on the system with
HMI Advanced.
Case 1 (see drawing):
1. On the system with HMI Advanced: Select the Services operating area.
2. Transfer display machine data to the display, if not yet activated:
Services → Data Selection
Select “Display machine data”
OK
3. Copy machine data:
Services → Manage Data
Display machine data\BDxxyy.tea
Copy
4. Select target directory:
Diagnostics\MachineData\OperatorPanel
Paste
5. Activate inserted display machine data via Start-up
Start-up → Machine Data → Display MD → File Functions
Set directory and BDxxyy.tea file
→ Load
Note
Systems with HMI Embedded manage more display machine data than systems
with HMI Advanced. A entry is made in the error log for all display machine data
that are offered but that are not defined in HMI Advanced or are faulty.
Display MD
Display MD
Display MD
Display MD
Network LW
HMI Embedded
HMI Embedded
HMI Advanced
HMI Advanced
