08/2005 Online Help (HE1)
1 Programming Help
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
HE1/1-13
The following screenshot shows an example:
Fig. 1-1 Siemens text file
A category definition contains the following parameters:
Category definition
Technology code "r"/Category ID/Category name
An instruction definition contains the following parameters:
Instruction definition
Technology/Category ID/Extended Help
/Instruction text/Descriptive text
Note
1. With reference to the individual text files, first the Siemens and then the
machine manufacturer and last the final user general category are displayed.
2. The order specified above appears only if the categories are defined first,
followed by the instruction declarations in the text file.
3. To provide correct sorting of the standard, machine manufacturer and final
user instructions, the instructions in the text files must be stored in the
alphabetical order.
