08/2005 Commissioning HMI Advanced (IM4)
3 Creating user alarm texts
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D Installation and Start-Up HMI (IAM) - 08/2005 Edition
IM4/3-153
The texts from the user files overwrite standard texts with the same alarm number.
Alarm numbers that do not already exist in the standard texts are added.
Structure of MBDDE.INI
Extract from MBDDE.INI relating to the configuration of alarm text files:
...
[Textfiles]
MMC=f:\dh\mb.dir\alm_
NCK=f:\dh\mb.dir\aln_
PLC=f:\dh\mb.dir\plc_
ZYK=f:\dh\mb.dir\alz_
CZYK=f:\dh\mb.dir\alc_
UserMMC=
UserNCK=
UserPLC=f:\dh\mb.dir\myplc_
UserZyk=
UserCZyk=
...
Editor
Any ASCII editor (e.g., the DOS editor edit) can be used for editing files. When
editing the text files with a different editor, make sure that they are then saved in
ASCII format.
Note
Changes in alarm texts do not take effect until the HMI is started up again. When
creating text files, make sure that the correct date and time are set on the PC.
Otherwise, the user texts may not appear on the screen.
Help on alarms
Creating user-specific online help texts is described in /HE1/ Installation and Start-
Up Guide HMI Online Help.
