Siemens SINUMERIK 840D Commissioning Manual

Expanding the Operator Interface (BE1) 08/2005
7 Configuring and Working Environment
© Siemens AG, 2005. All rights reserved
BE1/7-160 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Start softkeys
The start softkeys named here can be used to activate the associated configuration
files.
The possible start softkeys for screen forms are predefined. Additional start
softkeys are not possible. Access points are specific to operating areas.
SCxxx=File
SCxxx S
oftkey Connection (link between softkey and configuration file). xxx
represents one of the internal softkey identities for start softkeys listed
below
File
Name of configuration file
Access points in operating area:
Operating area
SCxxx Screen form:
MACHINE SC101 MACHINE JOG Horizontal SK 1
SC111 MACHINE MDA Horizontal SK 1
SC122 MACHINE AUTO Horizontal SK 2
PARAMETERS SC207 Main screen of PARAMETERS Horizontal SK 7
PROGRAM SC308 Main screen of PROGRAM Horizontal SK 8
SC312 1. softkey line of the editor Horizontal SK 2
SC313 1. softkey line of the editor Horizontal SK 3
SC314 1. softkey line of the editor Horizontal SK 4
SC315 1. softkey line of the editor Horizontal SK 5
SC316 1. softkey line of the editor Horizontal SK 6
SC326 2. Softkey menu of the editor Horizontal SK 6
SC327 2. Softkey menu of the editor Horizontal SK 7
SERVICES SC407 Main screen of SERVICES Horizontal SK 7
DIAGNOSIS SC507 Main screen of DIAGNOSIS Horizontal SK 7
IBN SC607 Main screen of START-UP Horizontal SK 7
SC616 2. Softkey menu of the editor Horizontal SK 6
SC617 2. Softkey menu of the editor Horizontal SK 7
ManualTurn SC702 More menu of basic menu Horizontal SK 2
SC703 More menu of basic menu Horizontal SK 3
SC704 More menu of basic menu Horizontal SK 4
SC705 More menu of basic menu Horizontal SK 5
SC706 More menu of basic menu Horizontal SK 6
SC707 More menu of basic menu Horizontal SK 7
ShopMill SC818 Machine Manual operating area Horizontal SK 8
SC8131 Machine Manual-Workpiece
Zero operating area
Vertical SK 1
SC8132 Machine Manual-Workpiece
Zero operating area
Vertical SK 2
SC8133 Machine Manual-Workpiece
Zero operating area
Vertical SK 3
SC8134 Machine Manual-Workpiece
Zero operating area
Vertical SK 4
SC8135 Machine Manual-Workpiece
Zero operating area
Vertical SK 5
