Expanding the Operator Interface (BE1) 08/2005
8 Terms, Tables, Lists, Examples
© Siemens AG, 2005. All rights reserved
BE1/8-182 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Table 8-4 HT6 main screen
HT6 main screen
Horizontal
softkey
Configuration file
Machine JOG 1 H_MA_JOG.COM
Machine MDA 1 H_MA_MDA.COM
Machine Automatic 2 H_MA_AUT.COM
Parameters 7 H_PARAM.COM
Parameters 8 H_PARAM.COM
Program 8 H_PROG.COM
Services 7 H_SERVIC.COM
Startup 7 H_STRTUP.COM
Editor 2, 3 H_EDITOR.COM
Correction editor 2, 3, 4 H_C_EDIT.COM
Table 8-5 HT6 keys
HT6 keys Configuration file
User key U1 H_U1.COM
User key U2 H_U2.COM
User key U3 H_U3.COM
User key U4 H_U4.COM
User key U5 H_U5.COM
User key U6 H_U6.COM
User key U7 H_U7.COM
User key U8 H_U8.COM
Special key S1 H_S1.COM
Special key S2 H_S2.COM
TEACH key H_TEACH.COM
Custom operating area
CUSTOM.COM
