Expanding the Operator Interface (BE1) 08/2005
8 Terms, Tables, Lists, Examples
© Siemens AG, 2005. All rights reserved
BE1/8-186 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
Name Index Description
$A_TC_LTO Target location number
$A_TC_MFN Source magazine
$A_TC_MFO Source magazine number
$A_TC_MTN Target magazine number
$A_TC_MTO Target magazine number
$A_TC_STATUS Command status
$A_TC_THNO Number of toolholder
$A_TC_TNO T number
$A_TIMERSI NCK time for Safe Programmable Logic
$A_TOOLMLN[x] x=ToolNo T Current location
$A_TOOLMN[x] x=ToolNo T Current magazine
$AA_COUP_ACT[x] x=Spindle following Current coupling status following spindle
$AA_COUP_OFFS[x] x=Axis Offset to leading axis/leading spindle, setpoint
$AA_COUP_OFFS[x] x=Spindle Position offset for synchronous spindle (setpoint)
$AA_CURR[x] x=Axis Actual current of axis or spindle in A
$AA_DELT[x] x=Axis Distance to go by the axes in WCS
$AA_DTBB[x] x=Axis Axial distance from block beginning in basic coord.
system
$AA_DTBW[x] x=Axis Axial dist. from block beg. in WCS
$AA_DTEB[x] x=Axis Axial distance from block end in basic coord. system
$AA_DTEPB[x] x=Axis Axial dist.-to-go infeed oscillation in basic system
$AA_DTEPW[x] x=Axis Axial dist.-to-go infeed oscillation in WCS
$AA_DTEW[x] x=Axis Axial dist. from block end in WCS
$AA_EG_ACTIVE
[a,b]
a=Following axis
b=Leading axis
EG coupling active
$AA_EG_AX[n,a] n=Leading axis
a=Following axis
EG leading axis number
$AA_EG_DENOM
[a,b]
a=Following axis
b=Leading axis
EG coupling factor denominator
$AA_EG_NUM_LA[a] a=Following axis EG no. of leading axes
$AA_EG_NUMERA
[a,b]
a=Following axis
b=Leading axis
EG coupling factor numerator
$AA_EG_SYN[a,b] a=Following axis
b=Leading axis
EG synchronous position leading axis
$AA_EG_SYNCDIFF
[a]
a=Axis identifier EG synchronism deviation
$AA_EG_SYNFA[a] a=Following axis EG synchronous position following axis
$AA_EG_TYPE[a,b] a=Following axis
b=Leading axis
EG coupling type
$AA_ESR_ENABLE
[a]
a=Axis ESR axis enable
$AA_ESR_ENABLE
[a]
a=Axis ESR enable
$AA_ESR_STAT[a] a=Axis ESR status
$AA_ETRANS[x] x=FrameNo Translation (offset) of external frames
$AA_FXS[x] x=Axis Status after travel to fixed stop
$AA_IBN[x] x=Axis Toolholder actual value
$AA_IEN[x] x=Axis Holder active tool rel. to workpiece zero
