08/2005 Starting Up HMI Embedded (IM2)
3 Communication/Initial Requirements
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/3-17
Licensing: All options
When you press the "All Options" softkey, all NCU and HMI options are displayed.
A description and order number are displayed for each option.
Options shown red are activated, however, not yet licensed or not licensed in
adequate number. You can set or reset the availability in the adjacent "Set" field.
After changing the option, press the "Apply" softkey.
Licensing: Missing licenses
When you press the "Missing Licenses" softkey, any insufficiently licensed options
will be listed.
You can set and reset the option in the adjacent field, as in the "All Options" menu.
Note
Use of non-licensed options.
Before licensing options, you can also activate them temporarily without the
license keys and use them for test purposes. In this case, the control displays
alarm 8080 periodically, indicating that the corresponding license has not been
allocated to the hardware.
The allocation of licenses to hardware is described in the following documentation:
References: /IDsl/ Installation and Startup Manual CNC Part 1 (NCK, PLC, Drive)
