08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-81
9242 MA_STAT_DISPLAY_BASE
H05
CR: K2
- Numerical basis for display of articulated position STAT WORD 3/4
Adv, Emb Adv: 10, Emb: 0
0 16
IMMEDIATE
LY
SW6.1
9243 MA_TU_DISPLAY_BASE
H05
CR: K2
- Numerical basis for display of rotary axis position TU WORD 3/4
Adv, Emb Adv: 10, Emb: 0
0 16
IMMEDIATE
LY
SW6.1
9246 USER_CLASS_SYS_ZERO_OFF
H04, H05
CR:
- Access level for writing system frames BYTE 2/2
Adv, Emb Adv: 7, Emb: 7
0 7
IMMEDIATE
LY
Adv. SW6.3,
Emb. SW6.2
9247 USER_CLASS_BASE_ZERO_OFF_PA
H04, H05
CR: K2
- Access level for basic offset PA BYTE 2/2
Adv, Emb Adv: 7, Emb: 7
0 7
IMMEDIATE
LY
SW5.3
9248 USER_CLASS_BASE_ZERO_OFF_MA
H04, H05
CR: IAM, IM1
- Access level for basic offset MA BYTE 2/2
Adv, Emb Adv: 7, Emb: 7
0 7
IMMEDIATE
LY
SW5.3
9249 USER_CLASS_VERT_MODE_SK
H04, H05
CR: K2
- Protection level for vertical SKs of area SKs
Protection for vertical SKs
DOUBLE 3/4
Emb Emb:
2004318071
0 0x77777777
IMMEDIATE
LY
SW6.1
9251 USER_CLASS_TM_SKTLLIST
H04, H05
CR: FBW
- Display tool list BYTE 3/4
Emb Emb: 7
0 7
Power On S 4.1
9252 USER_CLASS_TM_SKTOOLLOAD
H04, H05
CR: FBW
- Protection level for loading tools BYTE 3/4
Emb Emb: 7
0 7
Power On SW4.1
9253 USER_CLASS_TM_SKTOOLUNLOAD
H04, H05
CR: FBW
- Protection level for unloading tools BYTE 3/4
Emb Emb: 7
0 7
Power On SW4.1
9254 USER_CLASS_TM_SKTOOLMOVE
H04, H05
CR: FBW
- Protection level for relocating tools BYTE 3/4
Emb Emb: 7
0 7
Power On SW4.1
9256 USER_CLASS_TM_SKMGLREPR2
H04, H05
CR: FBW
- Protection level for displaying 2nd magazine list BYTE 3/4
Emb Emb: 7
0 7
Power On SW4.1
9257 USER_CLASS_TM_SKMGLREPR3
H04, H05
CR: FBW
- Protection level for displaying 3rd magazine list BYTE 3/4
Emb Emb: 7
0 7
Power On SW4.1
