Siemens SINUMERIK 840D Commissioning Manual

08/2005 Starting Up HMI Embedded (IM2)
4 Functions/Parameterization
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/4-83
9271 USER_CLASS_TM_SKLDTOOLDAT
H04, H05
CR: FBW
- Viewing and editing tool data BYTE 3/4
Emb Emb: 7
0 7
Power On SW4.1
9272 USER_CLASS_APPLICATION
H04, H05
CR:
- Protection level for selecting the operating area BYTE 3/4
Emb Emb: 7
0 7
IMMEDIATE
LY
SW6.4
9300 V24_USER_XON
H05
CR: C4
- User: X on character REAL 3/4
OP30, Emb OP30: 17, Emb:
17
0 0xFF
IMMEDIATE
LY
-
9301 V24_USER_XOFF
H05
CR: C4
- User: X off character REAL 3/4
OP30, Emb OP30: 19, Emb:
19
0 0xFF
IMMEDIATE
LY
-
9302 V24_USER_EOF
H05
CR: C4
- User: End of transmission character REAL 3/4
OP30, Emb OP30: 26, Emb:
26
0 0xFF
IMMEDIATE
LY
-
9303 V24_USER_CONTROLS
H05
CR: C4
- User: Special bits REAL 3/4
OP30, Emb OP30: 76, Emb:
76
0 0x3FF
IMMEDIATE
LY
-
9304 V24_USER_RTS
H05
CR: C4
- User: Line-controlled BYTE 3/4
OP30, Emb OP30: 1, Emb: 0
0 1
IMMEDIATE
LY
-
9305 V24_USER_BAUD
H05
CR: C4
- User: Baud rate
(300, 600, 1200, 2400, 4800, 9600, 19200)
0 1 ...
BYTE 3/4
OP30, Emb OP30: 4, Emb: 5
0 8
IMMEDIATE
LY
-
9306 V24_USER_DATABITS
H05
CR: C4
- User: Data bits BYTE 3/4
OP30, Emb OP30: 1, Emb: 1
0 1
IMMEDIATE
LY
-
9307 V24_USER_PARITY
H05
CR: C4
- User: Parity bits BYTE 3/4
OP30, Emb OP30: 0, Emb: 0
0 2
IMMEDIATE
LY
-
9308 V24_USER_STOPBIT
H05
CR: C4
- User: Stop bits BYTE 3/4
OP30, Emb OP30: 0, Emb: 0
0 1
IMMEDIATE
LY
-
9309 V24_USER_LINE
H05
CR: C4
- User: RS-232-C interface (COM1/COM2)
(COM1/COM2)
BYTE 3/4
Emb Emb: 1
1 2
IMMEDIATE
LY
SW5
