Starting Up HMI Embedded (IM2) 08/2005
5 Creating In-House Alarm Texts
© Siemens AG, 2005. All rights reserved
IM2/5-98 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
5.2 Number ranges of text files
Alarm numbers
The following alarm numbers are available for the cycle, compile cycle and PLC
alarms:
Table 5-1 Alarm numbers for cycle, compile-cycle and PLC alarms
Number range
Designation Effect Delete Name
000000 - 000320 Safety alarms
alsi.txt
085000 - 089990 User-cycle and tool-
management texts,
Amend texts for user
interface (wizard)
aluc.txt
065000 - 065999 Display, interlocking
NC Start
Reset
066000 - 066999 Display, interlocking
NC Start, motion stop after
execution of predecoded
blocks
Reset
067000 – 067999
Cycle alarms
(user)
Display Cancel
068000 - 069000 Reserved
alzu.txt
070000 - 079999 Compile cycle alarms
alc.txt
400000 - 499999 PLC alarms general
500000 - 599999 PLC alarms for
channel
600000 - 699999 PLC alarms for axis
and spindle
700000 - 709999 PLC alarms for user
800000 – 899999 PLC alarms for
sequence
cascades/graphs
alpu.txt
810000 - 810009 System messages in
the PLC
The number range in the list is not available with every number.
References: /DA/ Diagnostics Guide
