Starting Up HMI Embedded (IM2) 08/2005
5 Creating In-House Alarm Texts
© Siemens AG, 2005. All rights reserved
IM2/5-106 SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
5.7 Plain texts for PLC machine data
Application-specific and language-dependent plaintexts can be configured for each
index for so-called PLC machine data.
14510[i] User data (INT) i = 0 ... 255
14512[i] User data (HEX) i = 0 ... 255
14514[i] User data (FLOAT) i = 0 ... 31
Storage
Text files named NCTEA_xx.TXT (xx = language code deu, eng, etc.) can be
stored on the CompactFlash card in the following directories:
user\lng,
addon\lng or
oem\lng
Syntax
Plaintext number
Number: Number of the machine data item
Plain text: Plaintext of the machine data item, maximum 62 characters
(The plaintext cannot be enclosed by inverted comas.)
Machine data with different indices:
Number[x] plaintext
x: Index of the machine data item
Note
If a machine data item has different indices and you do not specify an index for
the plaintext, the same plaintext appears for all the indices of the machine data
item.
Note
PLC machine data plaintexts are created and handled in the same way as alarm
texts.
Display
The text for the selected machine data item is displayed below the machine data
list in the Start-up operating area.
â–
