08/2005 Starting Up HMI Embedded (IM2)
8 Diagnostics
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/8-119
Bit 5 = 1 Key actuations are logged
(default).
= 0 Key actuations are not logged.
Bit 6 = 1 Channel status/override is logged
(default).
= 0 Channel status/override is not logged.
Bit 7 = 1 HMI Advanced: Softkey actuations and menu
changes are logged.
For Siemens internal use only (default)
HMI Embedded: Identification number (ID) of
the open and closed window is logged. For
Siemens internal use only (default).
= 0 Softkey actuations and menu changes are
are not logged.
If the action log is enabled, the files that can be logged are logged by default.
The following events can be logged:
Alarm status
All displayed NC/PLC and HMI Embedded alarms and messages can be logged.
Actuate keys
All operator panel front and MF2 key actuations can be logged.
Channel status/override
NC/PLC statuses can be logged using information about the channel status and
the position of the override switch. At least in parts, if they can be recorded by time,
these statuses are used to verify the operation of the MCP.
Window ID
The identification number of a screen is logged when it is opened or closed.
