Siemens SINUMERIK 840D Commissioning Manual

08/2005 Starting Up HMI Embedded (IM2)
9 Configure Windows in the NC Program
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
IM2/9-131
Example 4: Position parameter
ANW.VAR TEST_2
1.000000
OK
To ensure that the cursor control works seamlessly, the configured fields must
overlap one another (see below):
Example 4: Position parameter
1.000000
OK
1.000000
1.000000
1.000000
