08/2005 Expanding the Operator Interface (BE1)
3 Syntax
© Siemens AG, 2005. All rights reserved
SINUMERIK 840D sl/840D/840Di/810D HMI Installation and Start-Up Guide (IAM) – 08/2005 Edition
BE1/3-53
Access mode
Table 3-5
Mode
M
Line value Z Column value S Output value
0 Line index Column index Value from line Z and
column S
1 Search concept,
search in column 0
Column index of
column from which
value is read
Value from line found
and column S
2 Line index of line
from which return
value is read
Search concept,
search in line 0
Value from line Z and
column found
3 Search concept,
search in column 0
Search concept,
search in line 0
Value from line and
column found
4 Search concept,
search in column S
Column index of search
column
Line index
5 Line index of search
line
Search concept,
search in line Z
Column index
Example
Two arrays are defined below. These are the basis for the following examples.
//A(Thread)
(0.3 / 0.075 / 0.202)
(0.4 / 0.1 / 0.270)
(0.5 / 0.125 / 0.338)
(0.6 / 0.15 / 0.406)
(0.8 / 0.2 / 0.540)
(1.0 / 0.25 / 0.676)
(1.2 / 0.25 / 0.676)
(1.4 / 0.3 / 1.010)
(1.7 / 0.35 / 1.246)
//END
//A(Array2)
