09-03-3
Section 09 TECHNICAL DATA
Sub-Section 03 (VEHICLES)
VEHICLE MODEL SUMMIT 500 SUMMIT 583 SUMMIT 670
GRAND TOURING
500
ENGINE TYPE 494 583 670 494
Chain Drive Ratio 22/44 22/44 23/44 23/44
Chain
Pitch in 3/8 3/8 3/8 3/8
Type/Links Qty/Plates Qty Silent 72-11 Silent 72-13 Silent 72-13 Silent 72-11
Drive Pulley
Type of Drive Pulley TRAC TRAC TRAC TRAC
Ramp Identification 287 ➄ 285 ➄ 286 ➄ 228 ➅
Calibration Screw Position or
Calibration Disc Quantity ➄
5553
Spring Color Pink/White Green/Blue Violet/Yellow Violet/Violet
Spring Length
± 1.5 mm
(± 0.060 in)
124.5
(4.90)
147.4
(5.80)
157.9
(6.22)
107
(4.21)
Clutch Engagement ± 200 RPM 4800 4500 4100 3500
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
7.0 (15.4)
50°
7.0 (15.4)
50°
7.0 (15.4)
50°
7.0 (15.4)
44°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
Drive Belt Part Number (P/N) 415 8607 00 415 0603 00 415 0603 00 414 8607 00
Drive Belt Width (new) ➀ mm (in) 34.7 (1-3/8) 35.0 (1-3/8) 35.0 (1-3/8) 34.90 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0) 38.1 (15.0)
Length cm (in) 345.5 (136) 345.5 (136) 345.5 (136) 345.5 (136)
Adjustment
Deflection
mm
(in)
45 – 50
(1-3/4 – 1-31/32)
45 – 50
(1-3/4 – 1-31/32)
45 – 50
(1-3/4 – 1-31/32)
40 – 55
(1-9/16 – 2-5/32)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track SC-10 Mountain SC-10 Mountain SC-10 Mountain SC-10 Touring
Ski DSA DSA DSA DSA
Length cm (in) 291.9 (114.9) 291.9 (114.9) 291.9 (114.9) 291.9 (114.9)
Width cm (in) 108 (42.5) 108 (42.5) 108 (42.5) 120.7 (47.5)
Height cm (in) 108 (42.5) 108 (42.5) 108 (42.5) 122 (48)
Ski Stance cm (in) 94 (37) 94 (37) 94 (37) 106.7 (42.0)
Mass (dry) kg (lb) 225 (494) 231 (508) 233 (513) 245 (539)
Ground Contact Area
cm
2
(in
2
)
7479.2 (1159.2) 7479.2 (1159.2) 7227.2 (1120.2) 7479.2 (1159.3)
Ground Contact Pressure kPa (PSI) 2.95 (.428) 3.03 (.439) 3.06 (.444) 3.21 (.465)
Frame Material Aluminum Aluminum Aluminum Aluminum
Bottom Pan Material Impact Copolymer Impact Copolymer Impact Copolymer Impact Copolymer
Cab Material RRIM RRIM RRIM RRIM
Battery V (A•h) N.A. N.A. 12 (22) 12 (22)
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Buld W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Buld W N.A. N.A. N.A. 3
Fuse
Starter Solenoid A N.A. N.A. N.A. 30
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 40 (10.6) 40 (10.6) 40 (10.6) 40 (10.6)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 250 (8.5) 250 (8.5) 250 (8.5)
Cooling System L (U.S. oz) 5.0 (169) 5.0 (169) 5.0 (169) 5.0 (169)
Injection Oil Reservoir L (U.S. oz) 2.8 (94.7) 2.8 (94.7) 2.8 (94.7) 2.8 (94.7)
