Section 09 TECHNICAL DATA
Sub-Section 03 (VEHICLES)
09-03-4
VEHICLE MODEL
GRAND TOURING
583
SKANDIC WT SKANDIC SWT SKANDIC WT LC
ENGINE TYPE 583 503 503 494
Chain Drive Ratio 23/44 N.A. N.A. N.A.
Chain
Pitch in 3/8 N.A. N.A. N.A.
Type/Links Qty/Plates Qty Silent 72-13 N.A. N.A. N.A.
Drive Pulley
Type of Drive Pulley TRAC TRAC TRAC TRAC
Ramp Identification 285 ➄ 146 ➄ 146 ➄ 146 ➄
Calibration Screw Position or
Calibration Disc Quantity ➄
3342
Spring Color Blue/Blue Blue/Violet Red/Yellow Blue/Orange
Spring Length
± 1.5 mm
(± 0.060 in)
99.6
(3.929)
96.6
(3.80)
87.9
(3.46)
132.6
(5.22)
Clutch Engagement ± 200 RPM 3800 3300 2900 3400
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
6.1 (13.45)
47°
7 (15.4)
40°
6 (13.2)
40°
7 (15.4)
40°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
32.75
(1-19/64)
32.75
(1-19/64)
32.75
(1-19/64)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8) 36.25 (1-27/64) 36.25 (1-27/64) 36.25 (1-27/64)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
1.0 – 2.0
(0.039 – 0.079)
Drive Belt Part Number (P/N) 414 8607 00 414 6338 00 414 6338 00 414 6338 00
Drive Belt Width (new) ➀ mm (in) 34.90 (1-3/8) 34.60 (1-3/8) 34.60 (1-3/8) 34.60 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25) 11.3 (25) 11.3 (25) 11.3 (25)
Track
Width cm (in) 38.1 (15.0) 50.0 (19.7) 60.0 (23.6) 50.0 (19.7)
Length cm (in) 345.5 (136) 394 (155.1) 394 (155.1) 394 (155.1)
Adjustment
Deflection
mm
(in)
40 – 55
(1-9/16 – 2-5/32)
40 – 50
(1-9/16 – 1-31/32)
40 – 50
(1-9/16 – 1-31/32)
40 – 50
(1-9/16 – 1-31/32)
Force ➂ kg (lbf) 7.3 (16) 7.3 (16) 7.3 (16) 7.3 (16)
Suspension Type
Track SC-10 Touring Skandic WT Skandic WT Skandic WT
Ski DSA Telescopic Strut Telescopic Strut Telescopic Strut
Length cm (in) 291.9 (114.9) 302.0 (118.9) 315.0 (124.0) 302.0 (118.9)
Width cm (in) 120 (47.5) 104.5 (41.1) 110.0 (43.3) 104.5 (41.1)
Height cm (in) 122 (48) 122 (48) 122 (48) 122 (48)
Ski Stance cm (in) 106.7 (42.0) 90.0 (35.4) 90.0 (35.4) 90.0 (35.4)
Mass (dry) kg (lb) 251 (553) 259 (569) 275 (605) 295 (627)
Ground Contact Area
cm
2
(in
2
)
7479.2 (1159.3) 10792.5 (1672.8) 13986 (2167.8) 12335 (1911.9)
Ground Contact Pressure kPa (PSI) 3.29 (.477) 3.29 (.477) 1.93 (.280) 2.27 (.329)
Frame Material Aluminum Steel Steel Steel
Bottom Pan Material Impact Copolymer HD Polyethylene HD Polyethylene HD Polyethylene
Cab Material RRIM Fiberglass Fiberglass Fiberglass
Battery V (A•h) 12 (22) 12 (22) 12 (22) 12 (22)
Headlight W H4 60/55 H4 60/55 H4 60/55 H4 60/55
Taillight and Stoplight W 8/27 8/27 8/27 8/27
Tachometer and Speedometer Buld W 2 x 3 2 x 3 2 x 3 2 x 3
Fuel and Temperature Gauge Buld W 3 N.A. N.A. N.A.
Fuse
Starter Solenoid A30303030
Tachometer A N.A. N.A. N.A. N.A.
Fuel Tank L (U.S. gal) 40 (10.6) 40 (10.6) 40 (10.6) 40 (10.6)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5) 500 (17) 500 (17) 500 (17)
Cooling System L (U.S. oz) 5.0 (169) N.A. N.A. N.A.
Injection Oil Reservoir L (U.S. oz) 2.8 (94.7) 2.55 (86) 2.55 (86) 2.55 (86)
