WIRING DIAGRAM 0
hal. = halogen
CHART CODES
Wiring Color Code
The first color of a wire is the main color, second
color is the stripe.
Example: YL/BK is a YELLOW wire with a BLACK
stripe.
MODEL
WIRING
DIAGRAM
PAGE
HEADLIGHT
(watt)
TAILLIGHT
(watt)
ELECTRICAL
SYSTEM
OUTPUT
(watt)
Formula III/III LT
Mach 1/Z/Z LT
Annex 1 60/55 hal. 8/27 220
COLOR CODE
BK — BLACK
WH — WHITE
RD — RED
BL — BLUE
YL — YELLOW
GN — GREEN
GY — GREY
VI — VIOLET
OR — ORANGE
BR — BROWN
