07-2
Section 07 TECHNICAL DATA
VEHICLE
VEHICLE MODEL GRAND TOURING SE
ENGINE TYPE 699
Chain Drive Ratio 25/44
Chain
Pitch in 3/8
Type/Links Qty/Plates Qty Silent/74/13
Drive Pulley
Type of Drive Pulley TRAC
Ramp Identification 286 ➅
Calibration Screw Position or
Calibration Disc Quantity
4
Spring Color Blue/Pink
Spring Length
± 1.5 mm
(± 0.060 in)
93.5
(3.68)
Clutch Engagement ± 200 RPM 3600
Driven Pulley Spring Preload
Cam Angle
± 0.7 kg (±1.5 lb)
degree
7.0 (15.4)
47°
Pulley Distance Z
(+ 0, –1) mm
((+ 0, –1/32) in)
16.5
(21/32)
Offset
X ± 0.4 mm (± 1/64 in) 35.0 (1-3/8)
Y – X MIN. – MAX.
mm
(in)
1.0 – 2.0
(0.039 – 0.079)
Drive Belt Part Number (P/N) 415 0603 00
Drive Belt Width (new) ➀ mm (in) 35.0 (1-3/8)
Drive Belt Adjustment
Deflection
± 5 mm
(± 13/64 in)
32
(1-1/4)
Force ➁ kg (lbf) 11.3 (25)
Track
Width cm (in) 38.1 (15.0)
Length cm (in) 345.5 (136)
Adjustment
Deflection
mm
(in)
35 – 40
(1-3/8 – 1-3/4)
Force ➂ kg (lbf) 7.3 (16)
Suspension Type
Track SC-10 Touring
Ski DSA
Length cm (in) 302.0 (118.9)
Width cm (in) 120.7 (47.5)
Height cm (in) 128.3 (50.5)
Ski Stance cm (in) 106.7 (42)
Mass (dry) kg (lb) 285 (628)
Ground Contact Area
cm
2
(in
2
)
7479 (1159)
Ground Contact Pressure kPa (PSI) 3.74 (.542)
Frame Material Aluminum
Bottom Pan Material Impact Copolymer
Hood Material RRIM Polyurethane
Battery V (A•h) 12 (22)
Headlight WH4 60/55
Taillight and Stoplight W 8/27
Tachometer and Speedometer Bulb W 2 x 3
Fuel and Temperature Gauge Bulb W 3/3
Fuse
Starter Solenoid A 30
Tachometer A N.A.
Fuel Tank L (U.S. gal) 42 (11.1)
Chaincase/Gearbox mL (U.S. oz) 250 (8.5)
Cooling System ➃ L (U.S. oz) 5.1 (172.5)
Injection Oil Reservoir L (U.S. oz) 4.1 (139)
