07-1
Section 07 TECHNICAL DATA
ENGINE
VEHICLE MODEL GRAND TOURING SE
ENGINE TYPE 699
Number of Cylinders 3
Bore mm (in) 69.75 (2.7461)
Stroke mm (in) 61.0 (2.402)
Displacement
cm
3
(in
3
)
699.2 (42.7)
Compression Ratio (corrected) 6.8
Maximum Power Engine Speed ➀ ± 100 RPM 8500
Piston Ring Type
1
st
/2
nd
ST/R
Ring End Gap
new
wear limit
mm (in)
mm (in)
0.2 (.008)
1.0 (.039)
Ring/Piston Groove Clearance
new
wear limit
mm (in)
mm (in)
0.03 (.0012)
0.2 (.008)
Piston/Cylinder Wall Clearance
new
wear limit
mm (in)
mm (in)
0.10 (.0039)
0.15 (.0059)
Connecting Rod Big End Axial Play
new
wear limit
mm (in)
mm (in)
0.39 (.0154)
1.2 (.0472)
Maximum Crankshaft End-play ➁ mm (in) 0.3 (.0118)
Maximum Crankshaft Deflection mm (in) 0.08 (.0031)
Rotary Valve Timing ➂ and P/N 420 924 XXX
Opening
Closing
N.A.
Magneto Generator Output W 360
Ignition Type CDI
Spark Plug Make and Type NGK BR9ES
Spark Plug Gap mm (in) 0.45 (.018)
Ignition Timing BTDC ➃ mm (in) 2.18 (.086)
Trigger Coil ➄ Ω 190 – 300
Generating Coil ➄
Low Speed Ω N.A.
High Speed Ω N.A.
Lighting Coil ➄ Ω 0.20 – 0.35
High Tension Coil ➄
Primary Ω 0.2 – 0.5
Secondary kΩ 6 – 13
Carburetor Type PTO/CTR/MAG VM 38-372/373/372
Main Jet PTO/CTR/MAG 350/350/350
Needle Jet 480 P-7
Pilot Jet 50
Needle Identification – Clip Position 6DEY2-4
Slide Cut-away 2.5
Float Adjustment ± 1 mm (± .040 in) 18.1 (.71)
Air Screw Adjustment ± 1/16 Turn 2-1/4
Idle Speed ± 200 RPM 1800
Gas Type/Pump Octane Number Super Unleaded/91
Gas/Oil Ratio Injection
Type Liquid
Axial Fan Belt Adjustment
Deflection ➅ mm (in) N.A.
Force kg (lbf) N.A.
Thermostat Opening Temperature °C (°F) 42 (108)
Radiator Cap Opening Pressure kPa (PSI) 90 (13)
ENGINE COLD
N•m (lb•ft)
Drive Pulley Retaining Screw ➆
Exhaust Manifold Nuts or Bolts 9 (6.6)
Magneto Ring Nut 125 (92)
Crankcase Nuts or Screws
M6
M8
13 (9.5)
22 (16)
Crankcase/Engine Support Nuts or Screws 13 (9.6)
Cylinder Head Nuts 29 (21)
Crankcase/Cylinder Nuts or Screws 29 (21)
Axial Fan Shaft Nut N.A.
