4-29
PDW-700/V1 (E)
BLACK/FLARE Display (Adjusting black/flare)
Item Setting Function
MASTER BLACK (_99 to 99) Adjusts the master black level
(All of the R, G and B black levels are adjusted)
R BLACK (_99 to 99) Adjusts the R black level
B BLACK (_99 to 99) Adjusts the B black level
MASTER FLARE (_99 to 99) Adjusts the master flare compensation level
(All of the R, G and B flare compensation levels are
adjusted)
R FLARE (_99 to 99) Adjusts the R flare compensation level
G FLARE (_99 to 99) Adjusts the G flare compensation level
B FLARE (_99 to 99) Adjusts the B flare compensation level
FLARE OFF/ON Turns ON/OFF the flare compensation function
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST
OUT connector
P03 BLACK/FLARE TOP
MASTER BLACK : 0
R BLACK : 0
B BLACK : 0
MASTER FLARE : 0
R FLARE : 0
G FLARE : 0
B FLARE : 0
FLARE : ON
TEST OUT SELECT : VBS
