4-30
PDW-700/V1 (E)
P04 GAMMA TOP
GAMMA : ON
STEP GAMMA : 0.45
MASTER GAMMA : 0
R GAMMA : 0
G GAMMA : 0
B GAMMA : 0
TEST OUT SELECT : VBS
GAMMA TABLE : STD
GAM TABLE (STD) : 5
ITU-R709
GAMMA Display (Adjusting gamma)
Item Setting Function
GAMMA OFF/ON Turns ON/OFF the gamma correction function
STEP GAMMA 0.35 to 0.90 (0.05 step)
Sets the master gamma correction curve for each step
MASTER GAMMA (_99 to 99) Adjusts the master gamma correction curve
R GAMMA (_99 to 99) Adjusts the R gamma correction curve
G GAMMA (_99 to 99) Adjusts the G gamma correction curve
B GAMMA (_99 to 99) Adjusts the B gamma correction curve
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST
OUT connector
GAMMA TABLE STD/HG Selects the gamma type
STD : Standard gamma
HG : Hyper gamma
GAM TABLE (STD) 1 to 6 Selects the standard gamma type
1 : Corresponds to SD camcorder
2 : x 4.5 gain
3 : x 3.5 gain
4 : Corresponds to SMPTE-240M
5 : Corresponds to ITU-R709
6 : x 5.0 gain
When HG is selected in GAMMA TABLE
Item Setting Function
GAM TABLE (HG) 1 to 4 Selects the hyper gamma type
1 : 325%
→
100%
2 : 460%
→
100%
3 : 325%
→
109%
4 : 460%
→
109%
GAMMA TABLE : HG
GAM TABLE (HG) : 4
HG4609
