4-31
PDW-700/V1 (E)
BLACK GAMMA Display (Adjusting black gamma)
Item Setting Function
BLACK GAMMA OFF/ON Turns ON/OFF the black gamma correction function
BLACK GAM RANGE LOW/L.MID/H.MID/HIGH Sets the range in which the black gamma correction is
effective
LOW : 0 to 3.6 %
L.MID : 0 to 7.2 %
H.MID : 0 to 14.4 %
HIGH : 0 to 28.8 %
MASTER BLK GAMMA (_99 to 99) Adjusts the master black gamma correction curve
(All of the R, G and B black gamma are adjusted)
R BLACK GAMMA (_99 to 99) Adjusts the R black gamma correction curve
G BLACK GAMMA (_99 to 99) Adjusts the G black gamma correction curve
B BLACK GAMMA (_99 to 99) Adjusts the B black gamma correction curve
TEST OUT SELECT VBS/Y/R/G/B/LCD Selects the video signal that is output from the TEST
OUT connector
KNEE Display (Adjusting knee)
Item Setting Function
KNEE OFF/ON Turns ON/OFF the knee correction function
KNEE POINT 50 to 109.0 (0.1 step) Adjusts the master knee point level during the manual
knee adjustment
KNEE SLOPE (_99 to 99) Adjusts the master knee slope level during the manual
knee adjustment
KNEE SATURATION OFF/ON Turns ON/OFF the knee saturation function
KNEE SAT LEVEL (_99 to 99) Adjusts the knee saturation level
WHITE CLIP OFF/ON Turns ON/OFF the white clip function
(used during the video signal adjustment)
Note : The video level that is higher than 109% is not
output even if this setting is set to OFF.
WHITE CLIP LEVEL 90.0 to 109.0
*
(0.1 step) Set the master white clip level
* : Default setting value is 108.0% when COUNTRY is set to “NTSC(J)AREA” or “NTSC AREA”, 105.0% when COUNTRY is set to “PAL
AREA”.
P05 BLACK GAMMA TOP
BLACK GAMMA : OFF
BLACK GAM RANGE : HIGH
MASTER BLK GAMMA: 0
R BLACK GAMMA : 0
G BLACK GAMMA : 0
B BLACK GAMMA : 0
TEST OUT SELECT : VBS
P06 KNEE TOP
KNEE : ON
KNEE POINT : 95.0
KNEE SLOPE : 0
KNEE SATURATION : ON
KNEE SAT LEVEL : 0
WHITE CLIP : ON
WHITE CLIP LEVEL: 108.0
