4-32
PDW-700/V1 (E)
P07 DETAIL 1 TOP
DETAIL : ON
APERTURE : ON
DETAIL LEVEL : 0
APERTURE LEVEL : 0
DTL H/V RATIO : 0
CRISPENING : 0
LEVEL DEPEND : ON
LEVEL DEPEND LVL: 0
DETAIL FREQUENCY: 0
DETAIL 1 Display (Adjusting-1 DETAIL)
Item Setting Function
DETAIL OFF/ON Turns ON/OFF the detail signal
APERTURE OFF/ON Turns ON/OFF the aperture correction function
DETAIL LEVEL (_99 to 99) Sets the overall detail signal level
APERTURE LEVEL (_99 to 99) Sets the aperture correction level
DTL H/V RATIO (_99 to 99) Sets the V. detail signal level only
CRISPENING (_99 to 99) Sets the range of video signal amplitude to which the
detail signal is crispening
LEVEL DEPEND OFF/ON Turns ON/OFF the level depend function
(This function decreases the amount of detail signal when
the video signal amplitude is small)
LEVEL DEPEND LVL (_99 to 99)
Sets the range of video signal amplitude that is suppressed
by the level depend
DETAIL FREQUENCY (_99 to 99) Sets the frequency (thickness) of the H. detail signal
DETAIL 2 Display (Adjusting-2 DETAIL)
Item Setting Function
KNEE APERTURE OFF/ON Turns ON/OFF the knee aperture function (This function
controls the amount of the detail signal that is added to
the highlight signal higher than the knee point)
KNEE APT LVL (_99 to 99) Adjusts the amount of the detail signal that is added to the
highlight signal higher than the knee point
DETAIL LIMIT (_99 to 99) Sets the both detail black and white limiters
DTL WHT LMT (_99 to 99) Limits the white peak of the detail signal
DTL BLK LMT (_99 to 99) Limits the black peak of the detail signal
DTL V-BLK LMT (_99 to 99) Limits the black peak of the V. detail signal
V DTL CREATION NAM/ G/ R+G/ Y Selects the source signal of the V. detail signal
H/V CONTROL MODE H/V / V Selects an operation mode of DETAIL H/V RATIO on the
DETAIL 1 page
H/V : Increase/decrease volume for H and V moves
in the opposite manner
V : Controls V DTL
P08 DETAIL 2 TOP
KNEE APERTURE : OFF
KNEE APT LVL : 0
DETAIL LIMIT : 0
DTL WHT LMT : 0
DTL BLK LMT : 0
DTL V-BLK LMT : 0
V DTL CREATION : R+G
H/V CONTROL MODE: V
