4-42
PDW-700/V1 (E)
AUDIO-2 Display (Setting-2 on audio)
Item Setting Function
AU DATA LEN(IMX)
*
16bit/24bit Sets the record format of audio
AU REF LEVEL _20 dB/_18 dB/_16 dB/ Sets the output level of the 1 kHz test signal
_12 dB/EBUL
AU REF OUT EBUL/0 dB/+4 dB/_3 dB Sets the output level with respect to the REF. level
AU CH12 AGC MODE MONO/STREO Selects whether to perform the auto adjustment on the
input level of the analog audio signals to be recorded on
CH1/CH2 separately for each channel, or in the stereo
mode
AU CH34 AGC MODE MONO/STREO/OFF Selects whether to perform the auto adjustment on the
input level of the analog audio signals to be recorded on
CH3/CH4 separately for each channel, or in the stereo
mode, or to turn it off
AU AGC SPEC _6 dB/_9 dB/_12 dB/ Sets the AGC characteristics (saturation level)
_15 dB/_17 dB
AU LIMITER MODE OFF/_6 dB/_9 dB/_12 dB/ Sets the limiter characteristics (saturation level) for large
_15 dB/_17 dB input signals during the manual adjustment of the audio
input level
AU OUT LIMITER OFF/ON Turns ON/OFF the audio output limiter
* : Displayed only when REC FORMAT is set to IMX50/40/30.
M07 AUDIO-2 TOP
AU DATA LEN(IMX): 16bit
AU REF LEVEL : -20dB
AU REF OUT : 0dB
AU CH12 AGC MODE: MONO
AU CH34 AGC MODE: MONO
AU AGC SPEC : -6dB
AU LIMITER MODE : OFF
AU OUT LIMITER : ON
To Next Page
