4-41
PDW-700/V1 (E)
BATTERY 2 Display (Setting-2 the battery-related items)
Item Setting Function
TYPE DETECTION
*
AUTO/OTHER AUTO: Automatically detects the type of the battery
OTHER: Always judges the battery to be of the
“OTHER” type regardless of the actual
battery type
SEGMENT NO.7 to NO.1 11.0 to 17.0 V (0.1 V steps) When the battery type judgment is “OTHER” , sets the
voltage level below which the battery status indicator
segment No.7 should turn off
* : When TYPE DETECTION in the BATTERY 2 page is set to “AUTO” , any batteries other than Sony BP series batteries and Anton
Bauer intelligent battery systems are classified as “Others”.
AUDIO-1 Display (Setting-1 on audio)
Item Setting Function
FRONT MIC SELECT MONO/STREO Selects whether to make the front microphone
monaural or stereo
AUDIO CH3/4 MODE CH1/2/SW Selects the input signal to be recorded on CH3/4
CH1/2 : Same signals as CH1 and CH2
SW : The input signals that are selected by the
AUDIO IN CH3, CH4 switches on the inside
panel
REAR XLR AUTO OFF/ON Turns ON/OFF the function that automatically detects
whether the connector is connected to the AUDIO IN
connector at the rear
FRONT MIC REF _60/_50/_40 dB Sets the reference input level of the front microphone
REAR MIC REF _60/_50/_40 dB Select the reference input level when AUDIO IN CH1 of
the rear is set to MIC
MIN ALARM VOL OFF/SET Volume of the monitor speaker alarm tone when it is
turned all the way down
OFF: Almost inaudible
SET: Faintly audible
SP ATT LEVEL OFF/3/6/9 dB Lowers the volume of the monitor speaker. Has no
effect on earphone volume
HEADPHONE OUT STREO/MONO Selects whether to make the rear earphone monaural
or stereo
M06 AUDIO-1 TOP
FRONT MIC SELECT: STREO
AUDIO CH3/4 MODE: SW
REAR XLR AUTO : OFF
FRONT MIC REF : -50dB
REAR MIC REF : -60dB
MIN ALARM VOL : OFF
SP ATT LEVEL : OFF
HEADPHONE OUT : MONO
M05 BATTERY 2 TOP
TAPE DETECTION : AUTO
<Other Battery Scale>
SEGMENT NO.7 : 17.0V
SEGMENT NO.6 : 16.0V
SEGMENT NO.5 : 15.0V
SEGMENT NO.4 : 14.0V
SEGMENT NO.3 : 13.0V
SEGMENT NO.2 : 12.0V
SEGMENT NO.1 : 11.0V
