4-44
PDW-700/V1 (E)
WRR SETTING Display (Setting on Wireless)
Item Setting Function
WRR VALID CH SEL ALL/CH1 Selects whether to enable channels 1 and 2 of the
wireless receiver, or channel 1 only
ALL : Enable both channel 1 and 2
CH1 :Enable channel 1 only. Select this setting to use
the wireless receiver as a monaural receiver
WRR CH SELECT
*2
TX1/TX2 Specifies the target channel for other items in this menu
TX1 : Channel 1
TX2 : Channel 2
WRR DELAY COMP
*2
OFF/ON Enables or disables the delay compensation function for
wireless audio input
OFF :Disables the function
ON : Enables the function (the audio in all EE output is
delayed by about 8 ms)
TX*
*1, *2
- Displays the name of the transmitter whose signals are
being received on the channel selected by WRR CH
SELECT
TX*
*1, *2
AUDIO PEAK PEAK Displays whether the AF level of the transmitter whose
signals are being received on the channel selected by
WRR CH SELECT is over the peak
TX*
*1, *2
INPUT LEVEL MIC/LINE Displays whether the input level of the transmitter whose
signals are being received on the channel selected by
WRR CH SELECT is set to MIC or LINE
TX*
*1, *2
ATT LEVEL - Sets the ATT level of the transmitter whose signals are
being received on the channel selected by WRR CH
SELECT (the permissible setting range may vary
depending on the transmitter device)
TX*
*1, *2
LCF FREQ - Sets the Low Cut Filter frequency of the transmitter
whose signals are being received on the channel
selected by WRR CH SELECT (the permissible setting
range may vary depending on the transmitter device)
TX*
*1, *2
SYSTEM DELAY AUTO/0.0 ms to 8.0 ms When WRR DELAY COMP is set to ON, sets the amount
of audio delay for the channel selected by WRR CH
SELECT
AUTO : Automatically adjusts the amount of delay so
that the delay in the audio received from the
wireless receiver is zero
0.0 ms to 8.0 ms :Sets the amount of anticipated cases
in several wireless systems are being
used over a device such as an audio
mixer
*1 : * indicates the channel number.
*2 : A setting for this item is required when the DWR-S01D Slot-In Digital Wireless Receiver is installed.
M09 WRR SETTING TOP
WRR VALID CH SEL: ALL
WRR CH SELECT : TX1
WRR DELAY COMP : ON
TX1 : -
TX1 AUDIO PEAK : PEAK
TX1 INPUT LEVEL : MIC
TX1 ATT LEVEL : 0dB
TX1 LCF FREQ : 200Hz
TX1 SYSTEM DELAY: AUTO
